Taconic RF-10 10mil Double-Layer PCB High-Dk Ceramic-PTFE Antenna Board For GPS and Patch Antennas
Taconic RF-10 10mil Double-Layer PCB High-Dk Ceramic-PTFE Antenna Board For GPS and Patch Antennas
Printed Circuit Boards are custom-made products; the images and specifications provided are for reference only.
1. RF-10 High-Dk Laminate
Taconic RF-10 PCBs represent advanced composite materials engineered for high-frequency applications. These laminates combine ceramic-filled PTFE with woven fiberglass reinforcement, delivering optimal electrical performance and mechanical stability. The unique composition provides both low dielectric loss and enhanced rigidity, facilitating easier handling and improved dimensional stability for precision RF circuits.
RF-10 substrates offer a cost-effective solution with industry-standard delivery times, specifically addressing the growing demand for circuit size reduction in RF applications. RF-10 laminate material demonstrates excellent bonding characteristics with smooth low-profile copper, while its low dissipation factor combined with ultra-smooth copper surfaces minimizes insertion losses - particularly crucial at higher frequencies where skin effect losses become significant.
2. PCB Construction & Specifications
Board Type: 2-Layer Rigid PCB
Base Material: RF-10 High Frequency Laminate
Quality Standard: IPC-6012 Class 2
Board Dimensions: 45mm x 50mm (±0.15mm)
Finished Thickness: 0.3mm
Copper Weight: 1oz (35μm) all layers
Minimum Trace/Space: 6/5 mils
Minimum Hole Size: 0.3mm
Blind Vias: Not Applicable
Via Plating Thickness: 20 μm
Surface Finish: Immersion Gold (ENIG)
Solder Mask: None (Top & Bottom)
Silkscreen: None (Top & Bottom)
Electrical Test: 100% tested prior to shipment
3. PCB Stackup Configuration
Layer 1: Copper - 35μm (1oz)
Core: RF-10 Laminate - 0.254mm (10mil)
Layer 2: Copper - 35μm (1oz)
4. Design Statistics
Component Count: 7
Total Pads: 29
Thru-Hole Pads: 21
SMT Pads (Top): 8
SMT Pads (Bottom): 0
Vias: 14
Nets: 2
Artwork Format: Gerber RS-274-X
5. Material Characteristics
Dielectric Constant: 10.2 ± 0.3 @ 10GHz
Dissipation Factor: 0.0025 @ 10GHz
Thermal Conductivity: 0.85 W/mK (Unclad)
CTE Values: X-axis 16 ppm/°C, Y-axis 20 ppm/°C, Z-axis 25 ppm/°C
Moisture Absorption: 0.08%
Flammability Rating: UL 94 V-0
6. Performance Advantages
Circuit Size Reduction through High Dielectric Constant
Superior Dimensional Stability Across Temperature Variations
Tight Dielectric Constant Tolerance for Design Accuracy
Enhanced Thermal Management via High Thermal Conductivity
Excellent Copper Adhesion for Reliable Interconnects
Low CTE in All Directions for Thermal Cycle Reliability
Outstanding Price-to-Performance Ratio
7. Target Applications
Microstrip Patch Antenna Arrays
GPS and GNSS Antenna Systems
RF Passive Components (Filters, Couplers, Power Dividers)
Aircraft Collision Avoidance and Radar Systems
Satellite Communication Components
Wireless Infrastructure Equipment
8. Global Availability
Taconic RF-10 PCB solution is available for global manufacturing and distribution, supporting prototyping and volume production requirements worldwide.
