RO3003 High frequency PCB
Shot 1: Introduction
RO3003 laminates are ceramic-filled PTFE-based circuit materials that offer a combination of electrical performance, mechanical stability, and cost-effectiveness. They provide a competitive solution for commercial microwave and RF applications, where high-frequency performance and consistent electrical characteristics are essential.
With its stable dielectric constant over temperature and frequency variations, Rogers RO3003 PCB is particularly well-suited for applications such as automotive radar (77 GHz), advanced driver assistance systems (ADAS), and 5G wireless infrastructure operating in mmWave frequency bands. These applications require precise and reliable performance, and the stability of RO3003 laminates helps ensure accurate signal propagation and optimal functionality.
Shot 2: Features & Benefits
RT/duroid 5880 features a dielectric constant (Dk) of 2.20 +/- .02, ensuring consistent signal propagation. Its low dissipation factor of .0009 at 10GHz minimizes energy loss during transmission, maintaining high signal integrity.
This material's moisture absorption is impressively low at 0.02%, making it well-suited for high humidity environments, as it retains its electrical and mechanical properties under such conditions.
The RT/duroid 5880 exhibits isotropic behavior, enabling uniform signal propagation in all directions, making it ideal for applications requiring multi-directional signal transmission.
In addition to its electrical properties, the RT/duroid 5880 laminate is easy to work with, allowing for efficient cutting, shaping, and machining. It exhibits resistance to solvents and reagents used in etching or plating processes, ensuring durability in harsh chemical environments.
As a well-established material, RT/duroid 5880 offers the lowest electrical loss among reinforced PTFE materials, enhancing signal integrity.
Shot 3: PCB Capability
Let's dive into the key specifications of our PCB offerings.
We provide flexibility in layer count, catering to various requirements including Single Sided, Double Sided, Multi-layer PCB, and even Hybrid PCB options.
You can choose from different copper weight options, such as 1oz (35µm) or 2oz (70µm), to meet your specific needs.
The dielectric thickness options range from 5mil (0.127mm) to 60mil (1.524mm), allowing for precise customization.
Our PCB size capability extends up to 400mm X 500mm, accommodating a wide range of project sizes.
When it comes to solder mask colors, we offer choices like Green, Black, Blue, Yellow, Red, and more.
For surface finish, you have a variety of options including Immersion gold, HASL, Immersion silver, Immersion tin, ENEPIG, OSP, Bare copper, and Pure gold, ensuring compatibility with your desired application.
PCB Capability (RO3003) |
|
PCB Material: |
Ceramic-filled PTFE composites |
Designation: |
RO3003 |
Dielectric constant: |
3.00± 0.04 |
Dissipation Factor |
0.001 10GHz |
Layer count: |
Single Sided, Double Sided PCB, Multilayer PCB, Hybrid PCB |
Copper weight: |
1oz (35µm), 2oz (70µm) |
PCB thickness: |
5mil (0.127mm), 10mil (0.254mm), 20mil (0.508mm), 30mil (0.762mm), 60mil (1.524mm ) |
PCB size: |
≤400mm X 500mm |
Solder mask: |
Green, Black, Blue, Yellow, Red etc. |
Surface finish: |
Immersion gold, HASL, Immersion silver, Immersion tin, ENEPIG, OSP, Bare copper, Pure gold etc.. |
Shot 4: Applications
With its exceptional performance, RO3003 PCBs are widely utilized in various industries. It is a go-to choice for automotive radar, global positioning satellite antennas, cellular telecommunications systems, patch antennas for wireless communications, remote meter readers, and power backplanes etc.
Thank you. I’ll see you next time.
