What is Hole Mounting in High Frequency PCB? |
|
|
|
| |
|
1. 1.Introduction to Hole Mounting |
|
|
|
| |
|
IIn high-frequency PCB design, hole mounting refers to the process of creating and utilizing plated through-holes (PTH) or non-plated holes (NPTH) to mount components, establish electrical connections, or enhance mechanical stability. This process is not just a manufacturing step but a critical factor influencing the reliability, signal integrity, and performance of high-frequency circuits. |
|
|
| |
|
|
|
|
| |
|
2. Why is Hole Mounting Important |
|
|
| |
|
High-frequency PCBs operate in a domain where even minor design flaws can cause issues like:
Signal distortion
Electromagnetic interference (EMI)
Impedance mismatches
Proper hole mounting ensures:
Robust electrical connections between layers
Minimal signal loss and interference
Mechanical stability for components under stress (e.g., thermal cycling, vibration)
By addressing these challenges, hole mounting becomes a key enabler for high-frequency PCB reliability. |
|
|
| |
|
|
|
|
| |
|
3. Key Considerations for Hole Mounting |
|
|
| |
|
To optimize performance in high-frequency PCBs, designers must focus on:
Hole size and plating thickness: Ensures durability and conductivity.
Alignment and placement: Prevents signal disruption.
Thermal and EMI management: Reduces interference while ensuring heat dissipation.
Impedance control: Maintains signal integrity for high-frequency signals.
Reliable hole mounting forms the foundation of high-frequency PCB performance, ensuring efficient communication across PCB layers and mechanical stability. |
|
|
| |
|
|
|
|
| |
|
4. Advantages of RO4830 Laminates in Through-Hole Installation |
|
|
| |
|
Rogers RO4830 laminates are thermoset materials with extremely low insertion loss, which is 2.2 dB/inch at 77 GHz. They possess a UL 94 V-0 flame retardant rating. Equipped with the optimized filler, resin and glass composite material system as well as the smooth LoPro® copper foil processed by inversion treatment, they are reliable in performance and cost-effective.They are Ideal for automotive radar sensor PCB applications.The RO4830laminates have obvious advantages in through-hole installation, as follows: |
|
|
| |
|
|
|
|
| |
|
 |
|
|
| |
|
|
|
|
| |
|
4.1 Material Characteristic Advantages |
|
|
| |
|
Rogers RO4830 high frequency PCBs , thermoset materials, are feature an optimized filler, resin, and glass composite material system. When combined with the smooth LoPro® copper foil processed by inversion treatment, they exhibit excellent oxidation resistance. |
|
|
| |
|
|
|
|
| |
|
4.2 Laser Drilling Advantages |
|
|
| |
|
The RO4830 substrate has excellent laser drilling performance. The through-hole wall is smooth and has high dimensional accuracy. Compared with some traditional materials, after laser drilling of the RO4830laminates, the roughness of the through-hole can be reduced by about 30%, thus better ensuring the quality of subsequent processes such as electroplating. |
|
|
| |
|
|
|
|
| |
|
4.3 Stable Dielectric Constant |
|
|
| |
|
The dielectric constant of the RO4830 is stable and consistent. The dielectric constant is 3.24 at 77 GHz, ensuring accurate transmission of high-frequency signals. When the signal is transmitted between different layers through the through-hole, the stable dielectric constant is like a stable "signal channel environment", which helps reduce signal distortion and improves the performance of the entire PCB in high-frequency applications. |
|
|
| |
|
|
|
|
| |
|
4.4 Cost Advantage |
|
|
| |
|
The RO4830 laminate reduces the overall cost of PCB manufacturing and reduces the reliance on special equipment and processes. Due to its material characteristics and good processing performance, in manufacturing links such as through-hole installation, it does not need to use complex through-hole pre-treatment or post-treatment processes like some high-performance but difficult-to-process materials, thus further reducing the overall cost of PCB manufacturing. |
|
|
| |
|
|
|
|
| |
|
5. RO4830 Datasheet |
|
|
| |
|
Designation: |
RO4830 |
PCB Material: |
Hydrocarbon/ Ceramic/ Spread Woven Glass |
Dielectric constant: |
3.24 |
Dissipation factor |
0.0033-0.0032 |
Layer count: |
Single Sided, Double Sided, Multi-layer PCB, Hybrid PCB |
Copper weight: |
1oz (35µm), 2oz (70µm) |
Dielectric thickness |
5mil (0.127mm), 9.4mil (0.239mm) |
PCB size: |
≤400mm X 500mm |
Solder mask: |
Green, Black, Blue, Yellow, Red etc. |
Surface finish: |
Immersion gold, HASL, Immersion silver, Immersion tin, ENEPIG, OSP, Bare copper, Pure gold etc. |
|
|
|
| |
|
6. Conclusion |
|
|
| |
|
Hole mounting in high-frequency PCBs is not just about making connections—it’s about ensuring long-term reliability and performance. As the saying goes, “High frequency lets signals fly, but hole mounting ensures a smooth flight.” |
|
|
| |
|
|
|
|
| |
|
