Rogers RT/Duroid 5870 PCB |
|
|
|
|
|
RT/duroid 5870 is glass microfiber reinforced PTFE composite of Rogers Corporation, which is designed for exacting stripline and microstrip circuit applications. |
|
|
|
|
|
|
|
|
Let's see the reasons for using RT/duroid 5870 material.
1) The randomly oriented microfibers result in exceptional dielectric constant uniformity.
2) The dielectric constant of RT/duroid 5870 laminates is uniform from panel to panel and is constant over a wide frequency range.
3) Its low dissipation factor extends the usefulness of RT/duroid 5870 laminates to Ku-band and above.
4) Designed for microstrip and stripline application |
|
|
PCB Capability |
|
|
| |
| PCB Material: |
Glass microfiber reinforced PTFE composites |
| Designation: |
RT/duroid 5870 |
| Dielectric constant: |
2.33 ±0.02 (process); 2.33 (design) |
| Layer count: |
1 Layer, 2 Layer, Multilayer, Hybrid type (Mixed) |
| Copper weight: |
0.5oz (17 μm), 1oz (35μm), 2oz (70μm) |
| PCB thickness: |
10mil (0.254mm), 20mil (0.508mm); 31mil (0.787mm), 62mil (1.575mm) |
| PCB size: |
≤400mm X 500mm |
| Solder mask: |
Green, Black, Blue, Yellow, Red etc. |
| Surface finish: |
Bare copper, HASL, ENIG, Immersion tin, OSP. |
|
|
|
|
RT/duroid 5870 is often used in double sided PCB, multilayer PCB and hybrid PCB.It's available in a variety of thicknesses for double sided PCB, such as 10mil, 20mil, 31mil and 62mil. Surface finishes are bare copper, HASL, ENIG, Immersion tine and OSP for option. |
|
|
|
|
|
|
|
|
The typical applications are microstrip and stripline circuits, commercial airline broadband antenna，radar systems, millimeter wave applications, point to point digital radio antenna etc. |
|
|
|
|
|
|
|
|
The basic colour of RT/duroid 5870 PCB is black. |
|
|
|
|
|
We specialize in providing you with prototype, small batches and mass production service. If you have any questions, please feel free to contact us.
Thank you for your reading. |
|
|
|
|
|
|
|
|
|
