Hello Everyone,
Today, we discuss high-frequency PCBs made from RT/duroid 6002 material.
RT/duroid 6002 is a low-loss, low-dielectric constant laminate designed to meet stringent mechanical reliability and electrical stability requirements in complex microwave structures. It is primarily composed of PTFE ceramic composites.
This material exhibits excellent resistance to temperature variations between -55 ℃ and 150 ℃, making it suitable for applications such as filters, oscillators, and delay lines due to its electrical stability. |
|
|
|
|
|
|
|
|
|
|
|
The main advantages |
|
|
1. Low loss provides outstanding high-frequency performance.
2. Exceptional mechanical and electrical properties ensure reliable multilayer board construction.
3. Extremely low thermal coefficient of dielectric constant guarantees excellent dimensional stability.
4. In-plane expansion coefficient matched to copper enables more reliable surface-mounted assemblies.
5. Low outgassing makes it ideal for space applications. |
|
|
|
|
|
 |
|
|
|
|
|
Typical applications |
|
|
1. Phased Array Antennas
2. Round Based and Airborne Radar Systems
3. GPS antennas
4. Power Backplanes
5. Commercial Airline Collision Avoidance |
|
|
|
|
|
Our PCB Capability (RT/duroid 6002) |
|
|
PCB Material: |
Ceramic-filled PTFE composite |
Designation: |
RT/duroid 6002 |
Dielectric constant: |
2.94 ±0.04 (process) |
|
2.94 (design) |
Layer count: |
1-layer, 2-layer, multi-layer, hybrid design |
Copper weight: |
1oz (35µm), 2oz (70µm) |
PCB thickness: |
10mil (0.254mm), 20mil (0.508mm), 30mil (0.762mm), 60mil (1.524mm), 120mil (3.048mm) |
PCB size: |
≤400mm X 500mm |
Solder mask: |
Green, Black, Blue, Yellow, Red etc. |
Surface finish: |
Bare copper, HASL, ENIG, Immserion Silver, Immersion tin, Pure gold, ENEPIG, OSP etc.. |
|
|
|
|
|
|
The base copper of RT/duroid PCBs is available in 0.5 oz, 1 oz, and 2 oz options. The PCB thickness varies widely, ranging from 5 mil to 120 mil, providing flexibility for our designers. |
|
|
|
|
|
 |
|
|
|
|
|
The standard color of RT/duroid 6002 PCBs is white.
RT/duroid 6002 PCBs are well-suited for both flat and non-planar structures, including antennas, complex multilayer circuits with inner-layer connections, and microwave circuits designed for aerospace applications in challenging environments.
If you have any questions, please don't hesitate to reach out. Thank you for reading! |
|
|
|
|
|
Appendix: Data Sheet of RT/duroid 6002 |
|
|
RT/duroid 6002 Typical Value |
Property |
RT/duroid 6002 |
Direction |
Units |
Condition |
Test Method |
Dielectric Constant,εProcess |
2.94±0.04 |
Z |
|
10 GHz/23℃ |
IPC-TM-650 2.5.5.5 |
Dielectric Constant,εDesign |
2.94 |
|
|
8GHz to 40 GHz |
Differential Phase Length Method |
Dissipation Factor,tanδ |
0.0012 |
Z |
|
10 GHz/23℃ |
IPC-TM-650 2.5.5.5 |
Thermal Coefficient of ε |
+12 |
Z |
ppm/℃ |
10 GHz 0℃-100℃ |
IPC-TM-650 2.5.5.5 |
Volume Resistivity |
106 |
Z |
Mohm.cm |
A |
ASTM D 257 |
Surface Resistivity |
107 |
Z |
Mohm |
A |
ASTM D 257 |
Tensile Modulus |
828(120) |
X,Y |
MPa(kpsi) |
23℃ |
ASTM D 638 |
Ultimate Stress |
6.9(1.0) |
X,Y |
MPa(kpsi) |
Ultimate Strain |
7.3 |
X,Y |
% |
Compressive Modulus |
2482(360) |
Z |
MPa(kpsi) |
|
ASTM D 638 |
Moisture Absorption |
0.02 |
|
% |
D48/50 |
IPC-TM-650 2.6.2.1
ASTM D 570 |
Thermal Conductivity |
0.6 |
|
W/m/k |
80℃ |
ASTM C518 |
Coefficient of Thermal Expansion
(-55 to 288℃) |
16
16
24 |
X
Y
Z |
ppm/℃ |
23℃/50% RH |
IPC-TM-650 2.4.41 |
Td |
500 |
|
℃ TGA |
|
ASTM D 3850 |
Density |
2.1 |
|
gm/cm3 |
|
ASTM D 792 |
Specific Heat |
0.93(0.22) |
|
j/g/k
(BTU/ib/OF) |
|
Calculated |
Copper Peel |
8.9(1.6) |
|
Ibs/in.(N/mm) |
|
IPC-TM-650 2.4.8 |
Flammability |
V-0 |
|
|
|
UL 94 |
Lead-free Process Compatible |
Yes |
|
|
|
|
|
|
|
|
|
|
