Premium-30mil-60mil-Thick-Taconic-TLF-35-High-Frequency-PCB-Featuring-Immersion-Gold, HASL, Immersion-Silver-and-Tin |
|
|
|
|
|
(As PCBs are custom - produced goods, the picture and parameters shown are only intended for reference.) |
|
|
|
|
|
Hello everyone, Today, we’ll be discussing the TLF-35 high-frequency PCB material.
Taconic’s TLF-35 is an advanced organic-ceramic laminate that utilizes woven glass reinforcement as its core structure. This material is engineered through a combination of innovative ceramic filler technology and a specialized coating of PTFE (polytetrafluoroethylene) on fiberglass. |
|
|
|
|
|
 |
|
|
|
|
|
We gain several key advantages from using TLF-35:
1. Enhanced Phase Intermodulation Distortion (PIMD) with Dk 3.5
TLF-35 is engineered to deliver superior PIMD performance, making it ideal for compact PCB designs in antenna applications. With a dielectric constant (Dk) of 3.5, it aligns perfectly with the requirements for optimal PIMD levels.
2. Superior Plated Through-Hole (PTH) Quality
This material ensures excellent PTH quality, providing stronger hole wall stability and improved insulation resistance, even for smaller drilled holes.
3. Exceptional High-Frequency Stability
TLF-35 is specifically designed to maintain outstanding performance in high-frequency environments, ensuring reliable signal integrity and minimal loss.
4. Ultra-Low Moisture Absorption
Thanks to its extremely low moisture absorption rate and low dissipation factor, TLF-35 minimizes phase shifts across varying frequencies, ensuring consistent performance.
5. Cost-Effectiveness
TLF-35 offers a cost-efficient solution, enabling high-volume production for commercial microwave and radio frequency applications without compromising on quality. |
|
|
|
|
 |
|
|
|
|
Typical applications |
|
|
1. Antenna
2. Power amplifiers (TD-SCDMA, WCDMAS, LTE, WLAN etc.)
3. LNA, Repeater PA
4. Passive RF components (Filters, Couplers etc.) |
|
|
|
|
|
Our PCB Capability (TLF-35) |
|
|
PCB Capability (TLF-35) |
PCB Material: |
Organic-ceramic, Woven glass reinforcement |
Designation: |
TLF-35 |
Dielectric constant: |
3.5 |
Dissipation Factor |
0.0022 10GHz |
Layer count: |
Double Sided PCB, Multilayer PCB, Hybrid PCB |
Copper weight: |
0.5oz (17 µm), 1oz (35µm), 2oz (70µm) |
PCB thickness: |
30mil (0.762mm), 60mil (1.524mm ) |
PCB size: |
≤400mm X 500mm |
Solder mask: |
Green, Black, Blue, Yellow, Red etc. |
Surface finish: |
Bare copper, HASL, ENIG, Immersion silver, Immersion tin, OSP, Pure gold plated etc.. |
|
|
|
|
|
|
We are pleased to offer TLF-35 high-frequency PCBs in a variety of configurations to meet your specific needs. Our capabilities include supplying boards with 1oz and 2oz copper weights, thicknesses of 0.8mm and 1.6mm, and a maximum panel size of 400 x 500mm. Additionally, we provide a range of surface finishes, such as bare copper, HASL (Hot Air Solder Leveling), ENIG (Electroless Nickel Immersion Gold), immersion tin, and more.
At Bicheng, we specialize in delivering tailored solutions, whether you require prototypes, small-batch orders, or large-scale mass production. Our team is dedicated to ensuring high-quality results and timely delivery.
If you have any inquiries or need further assistance, please don’t hesitate to reach out to us. We’re here to help!
Thank you for taking the time to read about our offerings. |
|
|
|
|
|
Appendix: Typical Values of TLF-35 |
|
|
TLF-35A Typcial Value |
Property |
Test Method |
Units |
Value |
Units |
Value |
Dielectric Constant @ 1.9 GHz |
IPC-TM650 2.5.5.5.1 Mod |
|
3.50 ±0.05 |
|
3.50 ±0.05 |
Dissipation Factor @ 1.9 GHz |
IPC-TM650 2.5.5.5.1 Mod |
|
0.0016 |
|
0.0016 |
Dissipation Factor @ 10 GHz |
IPC-TM650 2.5.5.5.1 Mod |
|
0.0022 |
|
0.0022 |
Water Absorption |
IPC-TM 650 2.6.2.1 |
% |
0.03 |
% |
0.03 |
Peel Strength (1 oz. copper) |
IPC-TM 650 2.4.8 |
Lbs./linear inch |
10 |
N/mm |
1.8 |
Volume Resistivity |
IPC-TM 650 2.5.17.1 |
Mohm·cm |
2.0 x 109 |
Mohm·cm |
2.0 x 109 |
Surface Resistivity |
IPC-TM 650 2.5.17.1 |
Mohm |
3.0 x 108 |
Mohm |
3.0 x 108 |
Flexural Strength Lengthwise |
IPC-TM 650 650 2.4.4 |
psi |
13000 |
N/mm2 |
90 |
Flexural Strength Crosswise |
IPC-TM 650 650 2.4.4 |
psi |
13000 |
N/mm2 |
90 |
Thermal Conductivity |
IPC-TM 650 2.4.50 |
W/m/K |
0.37 |
W/m/K |
0.37 |
x-y CTE (50 ~ 150℃) |
IPC-TM 650 2.4.41 |
ppm/℃ |
9-12 |
ppm/℃ |
9-12 |
z CTE (50 ~ 150℃) |
IPC-TM 650 2.4.41 |
ppm/℃ |
80 |
ppm/℃ |
80 |
Flammability |
UL-94 |
|
V-0 |
|
V-0 |
|
|
|
|
|
|
