Metal-Based-RF-PCB-with-Aluminum-or-Copper-Base-with-Immersion-Gold-for-Shielding-and-Heat-Dissipation |
|
|
|
|
|
(As PCBs are custom - produced goods, the picture and parameters shown are only intended for reference.) |
|
|
|
|
|
Brief Introduction |
|
|
Metal-based substrates are innovative composites designed for high-frequency applications. These substrates feature a core of high-frequency materials such as PTFE, sandwiched between specialized layers. On one side, a copper foil layer is applied, while the opposite side is coated with either a copper or aluminum base. This unique structure provides exceptional shielding and heat dissipation capabilities, making it ideal for demanding electronic environments. PCBs manufactured using these advanced materials are known as metal-based high-frequency PCBs.
Wangling offers a comprehensive range of high-frequency materials, including F4BM, F4BME, F4BTM, F4BTME, and F4BTMS. These materials are available with either aluminum or copper bases, catering to diverse application needs. For detailed specifications, please refer to the table below. |
|
|
F4BM and F4BME series aluminum/copper substrates |
|
|
Model |
Metal base |
Proportion |
Thermal Conductivity |
Available thicknesses of Copper or aluminum base |
Thickness tolerance of Metal base |
Availabe size |
F4BM217-AL |
Aluminum base |
2.7 |
180 W/mK |
0.48mm, 0.98mm, 1.48mm, 1.98mm, 2.98mm, 3.98mm, other thicknessnes are availabe for customization |
+0.02mm, -0.05mm |
460mm x 610mm (18"x24"), 460mm x 305mm (18"x12") |
F4BM220-AL |
F4BM233-AL |
F4BM245-AL |
F4BM255-AL |
F4BM265-AL |
F4BM275-AL |
F4BM294-AL |
F4BM300-AL |
F4BME217-AL |
F4BME220-AL |
F4BME233-AL |
F4BME245-AL |
F4BME255-AL |
F4BME265-AL |
F4BME275-AL |
F4BME294-AL |
F4BME300-AL |
F4BM217-CU |
Red copper brass |
8.9 |
380 W/mK |
F4BM220-CU |
F4BM233-CU |
F4BM245-CU |
F4BM255-CU |
F4BM265-CU |
F4BM275-CU |
F4BM294-CU |
F4BM300-CU |
F4BME217-CU |
F4BME220-CU |
F4BME233-CU |
F4BME245-CU |
F4BME255-CU |
F4BME265-CU |
F4BME275-CU |
F4BME294-CU |
F4BME300-CU |
|
|
|
F4BTM and F4BTME series aluminum/copper substrates |
|
Model |
Metal base |
Proportion |
Thermal Conductivity |
Available thicknesses of Copper or aluminum base |
Thickness tolerance of Metal base |
Availabe size |
F4BTM298-AL |
Aluminum base |
2.7 |
180 W/mK |
0.48mm, 0.98mm, 1.48mm, 1.98mm, 2.98mm, 3.98mm, other thicknessnes are availabe for customization |
+0.02mm, -0.05mm |
460mm x 610mm (18"x24"), 460mm x 305mm (18"x12") |
F4BTM300-AL |
F4BTM320-AL |
F4BTM350-AL |
F4BTME298-AL |
F4BTME300-AL |
F4BTME320-AL |
F4BTME350-AL |
F4BTM298-CU |
Red copper brass |
8.9 |
380 W/mK |
F4BTM300-CU |
F4BTM320-CU |
F4BTM350-CU |
F4BTME298-CU |
F4BTME300-CU |
F4BTME320-CU |
F4BTME350-CU |
|
|
|
F4BTMS series aluminum/copper substrates |
|
Model |
Metal base |
Proportion |
Thermal Conductivity |
Available thicknesses of Copper or aluminum base |
Thickness tolerance of Metal base |
Availabe size |
F4BTMS220-AL |
Aluminum base |
2.7 |
180 W/mK |
0.48mm, 0.98mm, 1.48mm, 1.98mm, 2.98mm, 3.98mm, other thicknessnes are availabe for customization |
+0.02mm, -0.05mm |
460mm x 610mm (18"x24"), 460mm x 305mm (18"x12") |
F4BTMS233-AL |
F4BTMS255-AL |
F4BTMS265-AL |
F4BTMS294-AL |
F4BTMS300-AL |
F4BTMS350-AL |
F4BTMS430-AL |
F4BTMS450-AL |
F4BTMS615-AL |
F4BTMS1000-AL |
F4BTMS220-CU |
Red copper brass |
8.9 |
380 W/mK |
F4BTMS233-CU |
F4BTMS255-CU |
F4BTMS265-CU |
F4BTMS294-CU |
F4BTMS300-CU |
F4BTMS350-CU |
F4BTMS430-CU |
F4BTMS450-CU |
F4BTMS615-CU |
F4BTMS1000-CU |
|
|
|
|
|
|
Our PCB Capability (F4B **-AL, F4B**-CU) |
|
|
PCB Capability (F4B**-AL / CU) |
PCB Material: |
PTFE，Ultra-thin and ultra-fine fiberglass, ceramics. |
F4B Aluminum / Copper Base |
F4B |
DK (10GHz) |
DF (10 GHz) |
|
F4BM**-AL |
2.17 - 3.00 |
0.001 - 0.0018 |
|
F4BME**-AL |
2.17 - 3.00 |
0.001 - 0.0018 |
|
F4BTM**-AL |
2.98 - 3.50 |
0.0018 - 0.0025 |
|
F4BTME**-AL |
2.98 - 3.50 |
0.0018 - 0.0025 |
|
F4BTMS**-AL |
2.94 -10.2 |
0.0009-0.0022 |
|
F4BM**-CU |
2.17 - 3.00 |
0.001 - 0.0018 |
|
F4BME**-CU |
2.17 - 3.00 |
0.001 - 0.0018 |
|
F4BTM**-CU |
2.98 - 3.50 |
0.0018 - 0.0025 |
|
F4BTME**-CU |
2.98 - 3.50 |
0.0018 - 0.0025 |
|
F4BTMS**-CU |
2.94 -10.2 |
0.0009-0.0022 |
Layer count: |
Single Sided / Single Layer |
Copper weight: |
1oz (35µm), 2oz (70µm) |
Dielectric thickness |
0.09mm (3.5mil), 0.127mm (5mil), 0.254mm(10mil),0.508mm(20mil), 0.635mm(25mil), 0.762mm(30mil), 0.787mm(31mil), 1.016mm(40mil), 1.27mm(50mil), 1.5mm(59mil), 1.524mm(60mil), 1.575mm(62mil), 2.03mm(80mil), 2.54mm(100mil), 3.175mm(125mil), 4.6mm(160mil), 5.08mm(200mil), 6.35mm(250mil) |
PCB size: |
≤400mm X 500mm |
Solder mask: |
Green, Black, Blue, Yellow, Red etc. |
Surface finish: |
Bare copper, HASL, ENIG, Immersion silver, Immersion tin, OSP, Pure gold, ENEPIG etc.. |
|
|
|
|
|
|
 |
|
|
|
|
|
