TLX delivers unmatched reliability for a broad spectrum of RF applications. With a dielectric constant (DK) range of 2.45 to 2.65 and a variety of thicknesses and copper cladding options, this PTFE-based fiberglass laminate is highly versatile. It is particularly well-suited for low-layer-count microwave designs, making it a top choice for radar systems, mobile communications, microwave test equipment, transmission devices, and RF components.
TLX stands out as a robust solution in the RF microwave substrate market. Its fiberglass reinforcement ensures exceptional performance in extreme environments, such as resistance to creep for PCBs bolted to housings during high-vibration space launches, high-temperature exposure in engine modules, radiation resistance in space, and durability in harsh conditions like warship antennas and altimeters exposed to wide temperature ranges during flight.
The TLX family includes TLX-0 (DK 2.45), TLX-9 (DK 2.50), TLX-8 (DK 2.55), TLX-7 (DK 2.60), and TLX-6 (DK 2.65). Available thicknesses range from 0.127mm to 6.35mm (5mil-250mil) for TLX-0, 0.05mm to 6.35mm (2mil-250mil) for TLX-9, 0.064mm to 6.35mm (2.5mil-250mil) for TLX-8, and 0.089mm to 6.35mm (3.5mil-250mil) for TLX-7 and TLX-6. |
|
|
Exceptional Mechanical and Thermal Performance
Low and Stable Dielectric Constant (DK)
Superior Dimensional Stability.
Low Moisture Absorption.
UL 94 V-0 Flame-Retardant Rating.
Tightly Controlled DK.
Low Dissipation Factor (DF).
Optimized for Low-Layer-Count Microwave Designs |
|
|
Antennas
Couplers, Splitters, Combiners,
Amplifiers, Mixers, Filters
Passive components |
|
