TLX is a reliable choice for a wide range of RF applications, offering versatility with a dielectric constant (DK) range of 2.45 to 2.65, along with various thicknesses and copper cladding options. It is particularly suitable for low layer count microwave designs.
As a PTFE-based fiberglass laminate, TLX is ideal for applications in radar systems, mobile communications, microwave test equipment, microwave transmission devices, and RF components.
This material excels in the RF microwave substrate sector, providing mechanical reinforcement in harsh environments. It resists creep in PCBs attached to housings that experience high vibration during space launches, withstands high temperatures in engine modules, shows radiation resistance in space applications, supports antennas for warships facing extreme sea conditions, and serves as a substrate for altimeters that encounter a wide range of temperatures during flight.
The TLX family includes:
TLX-0 (DK 2.45): Dielectric thickness from 0.127 mm to 6.35 mm (5 mil - 250 mil) TLX-9 (DK 2.50): Dielectric thickness from 0.05 mm to 6.35 mm (2 mil - 250 mil) TLX-8 (DK 2.55): Dielectric thickness from 0.064 mm to 6.35 mm (2.5 mil - 250 mil) TLX-7 (DK 2.60): Dielectric thickness from 0.089 mm to 6.35 mm (3.5 mil - 250 mil) TLX-6 (DK 2.65): Dielectric thickness from 0.089 mm to 6.35 mm (3.5 mil - 250 mil) |
