1. Introduction of TU-865
The TU-865 PCB material is a high-performance, halogen-free solution crafted from epoxy resin and E-glass fabric, designed to excel in harsh environments while delivering superior electrical performance and reliability. With a Tg of 200°C, UL94V-0 flammability rating, and 0.13% moisture absorption, it ensures stability in extreme thermal, chemical, and humid conditions. Compatible with AOI processes and featuring UV-blocking properties, TU-865 simplifies manufacturing while offering excellent dimensional stability and CAF resistance. Ideal for multilayer, single, and double-sided PCBs, it’s the perfect choice for automotive, aerospace, and industrial applications demanding high reliability and environmental safety. Elevate your designs with TU-865 – the material that combines performance, durability, and sustainability for the most challenging projects.
|
|
High Tg (DSC) reaching 200°C, with Tg(TMA) at 185°C
Dielectric constant of 4.4 at 10GHz
Dissipation factor of 0.014 at 10GHz
Markedly low coefficient of thermal expansion
Outstanding moisture resistance, maintaining at 0.13%
Fully compatible with lead-free processing
Robust Anti-CAF capability
Unparalleled through-hole and soldering reliability
Composed of environmentally friendly materials |
