Rogers 6010 High Frequency PCB Built on 50mil Substrate

  1.1 General description
  This is a type of double sidedPCB built on 50mil RT/duroid 6010LM substrate for the application of Patch Antennas. It's 1.3 mm finished thick without solder mask and with immersion gold on pads. Mininum tracks and gaps are 5mil and 5mil. All vias are designed to open air. It's supplied by individual PCB at 50mm x 100mm. They're fabricated per IPC 6012 Class 2 using supplied Gerber data. Each 25 boards are packed for shipment.

  1.2 Features and benifits


1. High dielectric constant for circuit size reduction
2. Low loss. Ideal for operating at X-band or below
3. Low moisture absorption. Reduces effects of moisture on electrical loss
4. Tight dielectric constant and thickness control for repeatable circuit performance
5. Strict WIP inspection and monitoring as well as working instruction
6. Delivery on time higher than 98% on-time-delivery rate
7. Eligible products rate of first production: >95%
8. More than 18 years of PCB experience
9. 8000 types of PCB's per month

  1.3 Applications
  1. Aircraft Collision Avoidance Systems
2. Ground Radar Warning Systems
3. Patch Antennas
4. Power Amplifiers
5. Satellite Communications Systems

  1.4 Parameter and data sheet

Base Material: RT/duroid 6010LM 50 mil (1.27 mm)
Copper Weight: 1 oz each layer
Board Thickness: 1.3 mm ±10%
Layer Count: 2 layers
Board Size: 50mm x100mm=1design = 1PCS
Solder Mask: No solder mask | black silkscreen
Surface Finish: Immersion gold
Via: via open
Warpage: ＜0.75%
Net Weight: 0.012 kg / PCS
Acceptable Standard: IPC-Class-2
Lead time for prototype: 10 working days
Shelflife: 6 months









　
